| Model |
BXT-BT-150 |
BXT-BT-300 |
BXT-BT-1L |
Maximum stirring capacity
(Customizable fixtures with different processing capacities) |
5ml-150ml*Single cup
(With 300ml container) |
5ml-350ml*Double cups
(With 600ml container) |
10ml-600ml*Double cups
(With 1000ml container) |
1g-150gSingle cup
(Dependent on the material density) |
1g-350g*Double cups
(Dependent on the material density) |
10g-600g*Double cups
(Dependent on the material density) |
| Compatible with syringes within the range of 3 to 30CC |
Compatible with syringes within the range of 3 to 55CC |
Compatible with syringes within the range of 5 to 200CC |
| Work method |
Vacuum, revolution, rotation, forward and reverse rotation, non-contact mixing mode |
Vacuum, revolution, rotation, forward and reverse rotation, non-contact mixing mode |
Vacuum, revolution, rotation, forward and reverse rotation, non-contact mixing mode |
| Revolution speed |
200 - 2000RPM
(adjustable) |
1- 3000RPM
(adjustable) |
10 - 2500 RPM
(adjustable) |
| Rotation speed |
200–2000 RPM (synchronized with orbital speed) |
1–3000 RPM
(synchronized with orbital speed) |
10–2500 RPM
(synchronized with orbital speed) |
| Orbital-rotational speed ratio |
1:1 (Not Optional) |
1:1 or separately adjustable by dual motors (optional) |
| Running time |
0-30min(adjustable) |
| Working cavity |
Single-chamber agitation |
Dual-chamber agitation |
| Machine size |
520*590*450(mm) |
580*450*620(mm) |
660*520*700(mm) |
| Weight |
About 85kg |
About 110kg |
About 130kg |
| Vacuum degree |
﹣98kpa Cannot be adjusted/
Built-in oil-free vacuum device |
﹣101kpa Adjustable/
Built-in oil-free vacuum device |
| Applicable environment |
Polymer materials / Lithium battery materials / Resin |
Resin/Silicone/AB glue/Transparent glue/Powder + Glue |
Silver paste / ink / slurry / hot molding body / medical aesthetics / encapsulation adhesive |
| Power |
Standby: 50W, Operating power consumption: 1.2kW |
Standby: 50W, Operating power consumption: 1.5kW |
Standby: 50W, Operating power consumption: 2kW |
| Production efficiency |
Stir the mixture for 1-5 minutes until the micrometer-sized bubbles are completely eliminated |
Stir the mixture for 1-3 minutes until the micrometer-sized bubbles are completely eliminated |
| Power supply |
AC220V±10%,50/60HZ |
| Equipment applicability |
Various flowing liquids are mixed with powders, solid materials, and are then agitated, defoamed, and dispersed. |
| Balance device |
Weight counterweight, mechanical bottom spring protection device, can work stably under a maximum unbalance of 20g |
Weight counterweight and mechanical bottom spring protection device, capable of stable operation under a maximum unbalance of 40g |
| Safety function |
Automatic shutdown due to failure / Shutdown upon opening the cover / Emergency stop |
Door lock alarm, vibration alarm, vacuum alarm, overload alarm, work completion prompt, emergency stop switch |
| Program storage capacity |
20 sets of programs, each set independently configured in 5 stages. Each stage can be adjusted for time, speed, direction, and vacuum capacity |
50 sets of programs, each set independently configured in 5 stages. Each stage can be adjusted for time, speed, direction, and vacuum capacity. |
